i26 – Ceiling AP 2.4GHz & 5GHz Wi-Fi6 1201Mbps

? Product Information

• Model: i26
• Category: Ceiling
• Dimension: Φ176 × 43.5 mm

? Hardware

• Interface: 1 × 10/100/1000 Mbps Ethernet Port (PoE)
• Button: 1 × Reset
• LED Indicator: 1 × SYS
• Maximum Power Consumption: 10.5 W
• Power Supply: PoE 802.3af
• Max. Number of Wireless Clients: 256
• Recommended Clients: 50
• Antenna Gain: 4 dBi
• 2.4GHz Max Power: CE <20 dBm, FCC <25 dBm
• 5GHz Max Power: CE <23 dBm, FCC <25 dBm
• Reception Sensitivity:
  • 2.4GHz 802.11b: -98 dBm
  • 2.4GHz 802.11n (MCS7): -77 dBm
  • 5GHz 802.11a: -95 dBm
  • 5GHz 802.11n (40M-MCS7): -76 dBm
  • 5GHz 802.11ax (80M-MCS11): -64 dBm

? Wireless Specifications

• Frequency Range: 2.4GHz & 5GHz
• Standard & Protocol: IEEE 802.11b/g/n/a/ac/ax (Wi-Fi6)
• Maximum Wireless Speed: 2.4GHz: 300 Mbps, 5GHz: 1201 Mbps
• Bandwidth: 20/40/80 MHz

? Software Features

• Operating Mode: AP / Client+AP
• Max No. of SSID: 2.4GHz: 8, 5GHz: 4
• Hide SSID, OFDMA, Beamforming, Fast Roaming (802.11k/v/r): Supported
• Security: WEP, WPA-PSK, WPA2-PSK, WPA, WPA2, WPA3-ASE
• Access Control, Adjustable Power, Automatic Channel, AP Isolation, Guest Network: Supported
• Connected Clients Control, RSSI Threshold, Weak Signal Terminal Elimination, Prioritize 5 GHz: Supported
• VLAN Tagging for SSID, LED Control, MU-MIMO, Diagnostics Tool: Supported
• Reboot at Specified Interval, Scheduled Reboot, Firmware Upgrade, Reset, Backup/Restore Configuration: Supported
• Device Management: Local Web Management, Tenda CloudFi Cloud Management, Tenda CloudFi APP Management, Tenda Gateway Management (G300-F / G0-8G-PoE / G0-5G-PoE / G1)
• System Logs: Supported

?️ Environment & Default Info

• Operating Temperature: -10℃ ~ 40℃
• Storage Temperature: -30℃ ~ 70℃
• Operating Humidity: 10% ~ 90% non-condensing
• Storage Humidity: 5% ~ 90% non-condensing
• Default Address: tendawifi.com / 10.16.16.169
